Growing plants is both an art and a science. About 95% of plants, either food crops or cash crops are grown in open field. Since time immemorial, man has learnt how to grow plants under natural environmental conditions. In some of the temperate regions where the climatic conditions are extremely adverse and no crops can be grown, man has developed methods of growing some high value crop continuously by providing protection from the excessive cold, which is called as Greenhouse Technology. So, Greenhouse Technology is the technique of providing favourable environment condition to the plants. It is rather used to protect the plants from the adverse climatic conditions such as wind, cold, precepitation, excessive radiation, extreme temperature, insects and diseases. It is also of vital importance to create an ideal micro climate around the plants. This is possible by erecting a greenhouse / glass house, where the environmental conditions are so modified that one can grow any plant in any place at any time by providing suitable environmental conditions with minimum labour. Greenhouses are framed or inflated structures covered with transparent or translucent material large enough to grow crops under partial or fully controlled environmental conditions to get optimum growth and productivity.

Advantages of greenhouses :

♥ The yield may be 10-12 times higher than that of out door
cultivation depending upon the type of greenhouse, type of
crop, environmental control facilities.
♥ Reliability of crop increases under greenhouse cultivation.
♥ Ideally suited for vegetables and flower crops.
♥ Year round production of floricultural crops.
♥ Off-season production of vegetable and fruit crops.
♥ Disease-free and genetically superior transplants can be
produced continuously.
♥ Efficient utilisation of chemicals, pesticides to control pest
and diseases.
♥ Water requirement of crops very limited and easy to control.
♥ Maintenance of stock plants, cultivating grafted plant-lets
and micro propagated plant-lets.
♥ Hardening of tissue cultured plants
♥ Production of quality produce free of blemishes.
♥ Most useful in monitoring and controlling the instability of
various ecological system.
♥ Modern techniques of Hydroponic (Soil less culture),
Aeroponics and Nutrient film techniques are possible only
under greenhouse cultivation.

GREENHOUSES – WORLD SCENARIO

There are more than 50 countries now in the world where cultivation of crops is undertaken on a commercial scale under cover. United States of America has a total area of about 4000 ha under greenhouses mostly used for floriculture with a turnover of more than 2.8 billion US $ per annum and the area under greenhouses is expected to go up considerably, if the cost of transportation of vegetables from neighbouring countries continues to rise.

The area under greenhouses in Spain has been estimated to be around 25,000 ha and Italy 18,500 ha used mostly for growing vegetable crops like watermelon, capsicum, strawberries, beans, cucumbers and tomatoes. In Spain simple tunnel type greenhouses are generally used without any elaborate environmental control equipments mostly using UV stabilised polyethylene film as cladding material.

In Canada the greenhouse industry caters both to the flower and off-season vegetable markets. The main vegetable crops grown in Canadian greenhouses are tomato, cucumbers and capsicum. Hydroponically grown greenhouse vegetables in Canada find greater preference with the consumers and could be priced as much as twice the regular greenhouse produce.

The Netherlands is the traditional exporter of greenhouse grown flowers and vegetables all over the world. With about 89,600 ha under cover, the Dutch greenhouse industry is probably the most advanced in the world. Dutch greenhouse industry however relies heavily on glass framed greenhouses, in order to cope up with very cloudy conditions prevalent all the year round. A very strong research and development component has kept the Dutch industry in the forefront.

The development of greenhouses in Gulf countries is primarily due to the extremity in the prevailing climatic conditions. Israel is the largest exporter of cut flowers and has wide range of crops under greenhouses (15,000 ha) and Turkey has an area of 10,000 ha under cover for cultivation of cut flowers and vegetables. In Saudi Arabia cucumbers and tomatoes are the most important crops contributing more than 94% of the total production. The most common cooling method employed in these areas is evaporative cooling.

Egypt has about 1000 ha greenhouses consisting mainly of plastic covered tunnel type structures. Arrangements for natural ventilation are made for regulation of temperature and humidity conditions. The main crops grown in these greenhouses are tomatoes, cucumbers, peppers, melons and nursery plant material.

In Asia, China and Japan are the largest users of greenhouses. The development of greenhouse technology in China has been faster than in any other country in the world. With a modest beginning in late seventies, the area under greenhouses in China has increased to 48,000 ha in recent years. Out of this 11,000 ha is under fruits like grapes, cherry, japanese persimon, fig, loquot, lemon and mango. The majority of greenhouses use local materials for the frame and flexible plastic films for glazing. Most of the greenhouses in China are reported to be unheated and use straw mats to improve the heat retention characteristics.

Japan has more than 40,000 ha under greenhouse cultivation of which nearly 7500 ha is devoted to only fruit orchards. Greenhouses in Japan are used to grow wide range of vegetables and flowers with a considerable share of vegetable demand being met from greenhouse production. Even a country like South Korea has more than 21,000 ha under greenhouses for production of flowers and fruits. Thus, greenhouses permit crop production in areas where winters are severe and extremely cold as in Canada and USSR, and also permit production even in areas where summers are extremely intolerable as in Israel, UAE, and Kuwait. Greenhouses in Philippines make it possible to grow crops inspite of excessive rains and also in moderate climates of several other countries. Thus, in essence greenhouse cultivation is being practiced and possible in all types of climatic conditions.

Status in India

While greenhouses have existed for more than one and a half centuries in various parts of the world, in India use of greenhouse technology started only during 1980’s and it was mainly used for research activities. This may be because of our emphasis, so far had been on achieving self-sufficiency in food grain production. However, in recent years in view of the globalization of international market and tremendous boost and fillip that is being given for export of agricultural produce, there has been a spurt in the demand for greenhouse technology. The National Committee on the use of Plastics in Agriculture (NCPA-1982) has recommended location specific trials of greenhouse technology for adoption in various regions of the country.

Greenhouses are being built in the Ladakh region for extending the growing season of vegetables from 3 to 8 months. In the North-East, greenhouses are being constructed essentially as rain shelters to permit off-season vegetable production. In the Northern plains, seedlings of vegetables and flowers are being raised in the greenhouses either for capturing the early markets or to improve the quality of the seedlings. Propagation of difficult-to-root tree species has also been found to be very encouraging. Several commercial floriculture ventures are coming up in Maharashtra, Tamil Nadu and Karnataka states to meet the demands of both domestic and export markets.

The commercial utilization of greenhouses started from 1988 onwards and now with the introduction of Government’s liberalization policies and developmental initiatives, several corporate houses have entered to set up 100% export oriented units. In just four years, since implementation of the new policies in 1991, 103 projects with foreign investment of more than Rs.80 crores have been approved to be set up in the country at an estimated cost of more than Rs.1000 crores around Pune, Bangalore, Hyderabad and Delhi. Thus the area under climatically controlled greenhouses of these projects is estimated to be around 300 ha. Out of which many have already commenced exports and have received very encouraging results in terms of the acceptance of the quality in major markets abroad and the price obtained.

Classification of greenhouses:

Greenhouse structure of various types are used for crop production. Although there are advantages in each type for a particular application, in general there is no single type greenhouse, which can be constituted as the best. Different types of greenhouses are designed to meet the specific needs. The different types of greenhouses based on shape, utility, material and construction are briefly given below:

1. Greenhouse type based on shape:
For the purpose of classification, the uniqueness of cross section of
the greenhouses can be considered as a factor. The commonly followed
types of greenhouses based on shape are:
a) Lean to type greenhouse.
b) Even span type greenhouse.
c) Uneven span type greenhouse.
d) Ridge and furrow type.
e) Saw tooth type.
f) Quonset greenhouse.
g) Interlocking ridges and furrow type Quonset greenhouse.
h) Ground to ground greenhouse.
2. Greenhouse type based on Utility

Classification can be made depending on the functions or utilities.

Of the different utilities, artificial cooling and heating are more expensive
and elaborate. Hence based on this, they are classified in to two types.

a) Greenhouses for active heating.
b) Greenhouses for active cooling.
3. Greenhouse type based on construction

The type of construction predominantly is influenced by structural material, though the covering material also influence the type. Higher the span, stronger should be the material and more structural members are used to make sturdy tissues. For smaller spans, simple designs like hoops can be followed. So based on construction, greenhouses can be classified as

a) Wooden framed structure.
b) Pipe framed structure.
c) Truss framed structure.
4. Greenhouse type based on covering material

Covering materials are the important component of the greenhouse structure. They have direct influence on greenhouse effect, inside the structure and they alter the air temperature inside. The types of frames and method of fixing also varies with covering material. Hence based on the type of covering material they may be classified as

a) Glass glazing.
b) Fibre glass reinforced plastic (FRP) glazing
i. Plain sheet
ii. Corrugated sheet.
c) Plastic film
i. UV stabilized LDPE film.
ii. Silpaulin type sheet.
iii. Net house.
d) Based on the cost of construction involved ( which includes various
factors mentioned from a to c )
i High cost Green House
ii Medium cost Green House
iii Low cost Green House

The structural requirements and the cost per unit area for different models of low cost green houses for cultivation of vegetables are detailed below with diagrams to enable an interested enterprenur to construct a low cost green house on his own accord. However, the local weather conditions and the individuals necessity play a major role in the selection of the model.

Cost Economics of High Cost Greenhouse

High cost green house may be a multispan structure. The cost estimates may vary considerably due to crop, cladding material and environmental control system. The additional cost involved per sq. m. is stated below.

Sl.No Specifications Cost Rs/m2
1 If double layer polyethylene
used
100
2. Co2 generation & distribution 150
3. Evaporative cooling 200
4 Heating system 100
5. Humidification system 100
6. Lighting 200
7. Night curtain / Shading system 150
8. Drip system 20
9. Nutrient application system 100
10 Porous flooring 100
11. Benches 150
12. Structural cost 300
13. Miscellaneous 180
Average cost of High Cost
Greenhouse per square metre Rs. 2000.00
Detailed estimate of material requirement for simple Pipe
framed low cost green house(4x25m)
Sl.No. Item of work / Detail of material Requirement (Qty)
1 G.I. Pipe of 25 mm. φ for foundation 50 x 1.20 =60m
2 G.I. Pipe of 15 mm. φ for arches and top M.S
Flates 19x8m
25 x 6 = 150m
25 x 1 = 25m
3 For sides for holding mesh and UV film and
front & backside &for purlins
120.00m run
4 M.S. ‘L’ angle19x19x3m for front and end
frames and door
28m run
5 Plastic beading 25 mm width 150 m
6 UV stabilised film (200 micron) 175 m2
7 Mesh 40-60 size all round (1.15m width) 65 m
8 Door frame and fitting L.S
9 Hardware like Bolts and nuts, welding rods,
Aluminium oxide, Painting etc.
L.S
10 Earth work and concreting of foundation
with 1: 3: 6
L.S
11 Labour cost L.S
Cost Economics of Simple, pipe framed green house ( 100 m2 )
Sl.
No Item of work Qnty.
Rate /
unit (Rs)
Total
amount
(Rs)
1 G.I. Pipe 25 mm dia.’B Class 60.0m 65.00/= 3900.00
2 G.I. Pipe 15 mm dia. ’B Class 175.0m 25.00/= 4375.00
3 M.S.Flat 19x3mm Size 80.0kg 16.50/kg 1320.00
4 M.S.L angle 19x19x3mm Size 20.0kg 17.50/kg 350.00
5 UV stabilised film 175.0m2 20.00/= 3500.00
6 Plastic beading 150.0m 4.00/= 600.00
7 Mesh 40-60 size all round 65.0m2 22.00/= 1430.00
8 Door frame and fitting L.S 425.00
9 Labour cost L.S 650.00
10 Bolts, nuts and welding rods L.S 400.00
11 Earth work and concreting of
foundation
L.S 550.00
Total 17,500.00
Average cost per square metre Rs.175.00
Cost Estimates of Medium Cost Green House (4 x 25 m2)
Sl. NO SPECIFICATION COST (Rs.)
1 Cost of Greenhouse (100m2 ) 17,5000.00
2 Additional items on GH-2 (for fans –2) 1000.00
3 Electrical Fittings (Power point distribution, boxes,
MCB etc)
3000.00
4 Mist spray assembly 2000.00
5 Inflation blower 1000.00
6 Two fans (60 Cm dia) 10000.00
7 Monoblock AC pump (3hp) 3500.00
8 Water tank (Sintex) 1000 liters 4000.00
9 Thermostat/ Humidstat 2000.00
10 Cooling pad and fittings ( local made) 3000.00
11 Labour (extra) 1500.00
12 Additional film for double layer 3500.00
Total expense 50,000.00
Cost of green house of medium type per square metre Rs.525.00
Detailed estimate of material requirement for construction
of low cost green house (27 x 18.5m = 500m2)
Sl.No Item of work / Detail of material Requirement, Qty
A Structural material
1 G.I. Pipe of 56 mm. φ for foundation 42.00m
2 G.I. Pipe of 50 mm. φ for foundation posts 120.00m
3 M.S. ‘L’ angle25x25x6m for arches + top & bottom
frame to fix mesh and film + for tie beams(102
lengths)
612.00m
4 Plastic beading 25 mm width 200.00m
5 Plastic pipes 25mm φ and 19mm φ as grippers. 100.00m.
(each)
6 Base plate for foundation post (50 x 50 x 6mm0 40.0 nos.
7 Welding rods 5 boxes
8 Hardware like Bolts and nuts, welding rods,
Aluminium oxide, Painting etc.
L.S
B Cladding material
1 UV stabilised film (200 Micron) 5.00 Bundles
2 Rambonet 40-60 mesh (1.15m width x 30.0m length 12.00 Bundles
C Construction material
1 Earth work excavation for foundation 4.00 m3
2 Sand filling for foundation and basement(optimal) 1.00 m3
3 Plain cement concrete for foundation 2.25 m3
4 Hollow cement bricks for foundation 3000.00nos
Detailed estimate of material requirement for construction of
medium cost ( single span) green house (33 x 9.1m = 300m2)

Sl.No. Item of work / Detail of material Requirement (Qty)
A Structural material
1 G.I. Pipe of 56 mm. φ for foundation 30.00m
2 G.I. Pipe of 50 mm. φ for foundation posts 90.00m
G.I. Pipe of 38 mm. φ for purlins & arches 205.00m
3 M.S. ‘L’ angle 25x25x3m for top & bottom
frame & door
150.00m
4 Plastic beading 25 mm width 200.00m
5 Plastic pipes 25mm φ and 19mm φ as
grippers.
70.00m. each
6 Base plate for foundation post (50 x 50 x
6mm φ
25.0 nos.
7 Welding rods 3 boxes
8 Hardware like Bolts and nuts, welding rods,
Aluminium oxide, Painting etc.
L.S
B Cladding material
1 UV stabilised film (200 Micron) 150.00Kg
C Cooling system ( fan 7 pad )
1 Fans ( air flow fans) 3.00 Nos
2 Pad ( 9.0m x 1.5 m) 1.0 Nos
D Construction material
1 Earth work excavation for foundation 1.25 m3
2 Plain cement concrete for foundation(
1:2:4)
1.25 m3
4 Hollow cement bricks for parapet wall 1000.00nos
Different shapes of the Greenhouse
Components of typical greenhouse
Gutter
Gutter Support
Ridge ventilator
Ridge
Truss
Purlin
Lateral
ventilator
Active cooling
Passive cooling

Pipe Framed
